FRAME Hydro formed 24" 6061 Aluminium, 11/8" Headtube 135mm OLD, QR Dropouts, disc brake mounts
FORK SR Suntour SF20 XCT-JR DS 24", 50mm Travel
HEADSET 1-1/8" Headset, Press in cups, Black
SPACER Alloy spacer, 10mm for 28.6mm Diameter Steerer.
BOTTOM BRACKET Square Tapered Bottom Bracket, BSA 68mm
HANDLEBAR 580mm x 25.4, 10°, H:15mm, Matt Black
STEM 25.4mm E:60mm H:41mm 15° , Alloy Black
GRIP TPR Grips, Custom Colour, 125mm
WHEELSET SURFACE Custom Wheelset
RIM-FRONT 24" Alloy Single Wall, 28H, Black
RIM-REAR 24" Alloy Single Wall, 28H, Black
HUB-FRONT F: Joytech, 100x9 QR, 6 Bolt, 28H Front Hub R: Joytech, 135x9 QR, 7-Speed, 6 Bolt, 28H Rear Hub
TIRE-FRONT 24 x 2.35" Wanda P1226
TIRE-REAR 24 x 2.35" Wanda P1226
SPOKE Spoke Protector for 28H
CASSETTE 8 Speed
CHAIN Shimano CN-HG40 Chain, 104 Links with End Pin
CRANKSET SURFACE Alloy Crank, 140mm, 32T chainring, Black
PEDAL 9/16? Ball, PP, Black
BRAKE-FRONT Tektro HD-J285 Hydraulic Disc Brake, Short Reach for Juniors
BRAKE-REAR Tektro HD-J285 Hydraulic Disc Brake, Short Reach for Juniors
ROTOR-FRONT Tektro 160mm, 6-Bolt Rotor
ROTOR-REAR Tektro 160mm, 6-Bolt Rotor
BRAKE LEVER-LEFT NIL
BRAKE LEVER-RIGHT NIL
DERAILLEUR-REAR Shimano RD-TX800 Tourney Rear Derailleur, 7/8-Speed, Black
SHIFTER-RIGHT Shimano SL-M315-8R Altus Shift Lever, 8-speed
FREEWHEEL Shimano CS-HG200-8 Cassette, 8-speed, 12-32T
SADDLE SURFACE Kids Saddle
SEAT POST 27.2mm x 300mm, Alloy Black
SEAT POST CLAMP 31.8mm w/o Logo, Alloy , Black, QR
KICKSTAND Kickstand, Steel, for 24"
MUDGUARD NIL
