FRAME Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, semi-internal cable routing, dropper post compatible, replaceable derailleur hanger
FRAME CONT. Integrated 40mm direct-mount 2-bolt kickstand mounts, water bottle bosses, 135mm x 10mm QR rear hub spacing, 27.5 & 29" x 2.35" tyre clearance, rack and fender mounts
FORK SR Suntour XCT30 Coil, 29" x 2.25", 100mm Travel, Hydraulic Lockout with Preload Adjuster
HEADSET Semi-Integrated Threadless Headset
HANDLEBAR Alloy Handlebar, Dia: 31,8mm, 680mm, 9° Backsweep, 12mm Rise, Sanblasted Black
STEM Alloy Stem, 31.8mm, ±6° Rise
GRIP PVC Grips, 120mm, Black
WHEELSET SURFACE Custom Wheelset
RIM-FRONT 29" Symmetrical Alloy Rim, Tubeless Ready
RIM-REAR 29" Symmetrical Alloy Rim, Tubeless Ready
HUB-FRONT Shimano HB-QC300 Front Hub, QR, 32H, 100mm OLD, Centre Lock, Black
HUB-REAR Shimano FH-QC300-HM Freehub, Centre Lock, 32H, 8-11 Speed, OLD: 135mm, QR: 170mm
TIRE-FRONT CST 1820 29x2.10"
TIRE-REAR CST 1820 29x2.10"
SPOKE 14G Stainess Black Spokes
CHAIN Shimano CN-HG40 Chain, 116 Links with End Pin
CRANKSET Shimano FC-U2000-1 Essa Chainwheel, 32T, 7/8 Speed
CHAINRING NIL
PEDAL One Piece PP Pedal, Black
BRAKE-FRONT Shimano BL-MT200(L) with BR-MT200(F) Altus Disc Brake Assembled Set, 800mm Hose
BRAKE-REAR Shimano BL-MT200(R) with BR-MT200(R) Altus Disc Brake Unassembled Set, 1700mm Hose
ROTOR-FRONT Shimano SM-RT10 Rotor, 180mm, with Lock Ring
ROTOR-REAR Shimano SM-RT10 Rotor, 160mm, with Lock Ring
DERAILLEUR-FRONT NIL
DERAILLEUR-REAR Shimano RD-U2000 Essa Rear-Derailleur, 8-Speed, Top normal Shadow Design, Direct Attachment
SHIFTER-LEFT NIL
SHIFTER-RIGHT Shimano SL-M315-8R Altus Shift Lever, 8-speed
CASSETTE Shimano CS-GH400-8 Cassette, 11-45T, 8-Speed
SADDLE Nylon Base Saddle, Black
SEAT POST Alloy, 30.9mm, Black Seat Post
SEAT POST CLAMP Alloy 34,9mm QR Clamp
