FRAME Hydroformed tubing, Tapered headtube, T6 - 6061 Aluminium, external cable routing, dropper post compatible, replaceable derailleur hanger
FRAME CONT. Integrated 40mm direct-mount 2-bolt kickstand mounts, water bottle bosses, 135mm x 10mm QR rear hub spacing, 27.5 & 29" x 2.35" tyre clearance, rack and fender mounts
FORK SR Suntour XCE28 Coil, 29"x2.25", 100m Travel, Preload Adjuster
HEADSET Semi-Integrated Threadless Headset
HANDLEBAR Alloy Handlebar, Dia: 31,8mm, 680mm, 9° Backsweep, 30mm Rise, Sanblasted Black
STEM Alloy Stem, 31.8mm, ±3° Rise
GRIP PVC Grips, 120mm, Black
WHEELSET SURFACE Custom Wheelset
RIM-FRONT 29" Symmetrical Alloy Rim, Tubeless Ready
RIM-REAR 29" Symmetrical Alloy Rim, Tubeless Ready
HUB-FRONT Alloy Front Hub, 100x9mm QR, 6 Bolt
HUB-REAR Alloy Rear Hub, 135x9mm QR, Freewheel, 6 Bolt
TIRE-FRONT CST 1820 29x2.10"
TIRE-REAR CST 1820 29x2.10"
SPOKE 14G Stainess Black Spokes
CHAIN KMC Z7 GYBR Chain, 112 Links
CRANKSET Shimano FC-TY301 Front Chainwheel, 42x34x24T
CHAINRING NIL
PEDAL One Piece PP Pedal, Black
BRAKE-FRONT Shimano BR-M375-L Cable Disc Brake, Resin Pad, with SM-MA-F180P/P2 Adapter
BRAKE-REAR Shimano BR-M375-L Cable Disc Brake, Resin Pad, with Standard Adapter
ROTOR-FRONT Shimano SM-RT26 Rotor, 180mm, 6-Bolt
ROTOR-REAR Shimano SM-RT26 Rotor, 160mm, 6-Bolt
DERAILLEUR-FRONT Shimano FD-TY600-L6 Tournet Front Derailleur, Top-Swing
DERAILLEUR-REAR Shimano RD-TY300 Rear Derailleur, 6/7-speed
SHIFTER-LEFT Shimano ST-EF41-L Shift/Brake Lever, 3-speed
SHIFTER-RIGHT Shimano ST-EF41-7R Shift/Brake Lever, 7-Speed
CASSETTE Shimano MF-TZ510-7 Freewheel Sprocket, 7-Speed, 14-28T
SADDLE Nylon Base Saddle, Black
SEAT POST Alloy, 30.9mm, Black Seat Post
SEAT POST CLAMP Alloy 34,9mm QR Clamp
