01. FRAME SuperFoxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 160mm travel, Forward Geometry, one piece Monoblock upper link, SuperBoost 12x157mm rear axle, tapered head tube, 73mm
01A. FRAME Dedicated 1x drivetrain design, telescopic seatpost internal routing, Max. capacity sealed bearings, ISCG 05
02. FORK Fox 38 29 Float GRIP RHYTHM, 170mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
03. REAR SHOCK Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
04. SHOCK SETTINGS Medium compression, Medium rebound, 0.2 air volume spacer
05. HEADSET Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree
06. STEM Onoff Sulfur FG 30mm 0 degree, 6061 forged alloy, 31.8mm barbore
07. HANDLEBAR Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore
08. GRIPS Onoff Twin, 1lock-on, 135mm
09. SEATPOST Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
10. SADDLE SDG BEL-AIR 3.0, LPU foam, steel rails
11. FRONT BRAKE Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
12. REAR BRAKE Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
13. BRAKE LEVER Sram DB8, tool-free reach adjust
14. FRONT HUB e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
15. REAR HUB e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub
16. FRONT TIRE Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
17. REAR TIRE Maxxis Dissector 29x2.4WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
18. CRANKSET Truvativ Descendant 7K Eagle, SuperBoost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
19. RINGS 32T, CNC-machined alloy, X-SYNC 2
20. BOTTOM BRACKET Sram DUB BSA, sealed bearings, 73mm
21. PEDALS N/A
22. CHAIN Sram SX Eagle, 12s, Powerlock
23. REAR DERAILLEUR Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
24. CASSETTE Sram PG-1210, 11-50T, 12s
25. DERAILLEUR HANGER Mondraker M068
26. SIZES S: 380mm / M: 420mm / L: 470mm / XL: 510mm
