01. FRAME Level 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 170mm travel, Forward Geometry, internal non-removable battery
01A. FRAME Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive p
02. FORK Ohlins RXF 38 M.2 29, 180mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound,
03. REAR SHOCK Ohlins TTX22M 225x75mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, spring preload. Trunnion top mount, 25x10mm bottom bushings
04. SHOCK SETTINGS C10 compression, R35 rebound. Spring rate: S size 251 lbs, M size 297 lbs, L size 343 lbs, XL size 411 lbs
05. HEADSET Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreex45 degree, bottom 51.9x40x8x45 degreex45 degree
06. STEM Onoff Krypton FG 30mm, CNC, 31.8mm barbore
07. HANDLEBAR Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9 degree backsweep, 5 degree upsweep, 31.8mm barbore
08. GRIPS Onoff Desert, 1lock-on, 135mm
09. SEATPOST Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm
10. SADDLE FIZIK Terra Aidon X5 145mm
11. FRONT BRAKE Sram Code RSC, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
12. REAR BRAKE Sram Code RSC, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
13. BRAKE LEVER Sram Code RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
14. FRONT HUB e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts
15. REAR HUB e*thirteen Boost 12x148mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts
16. FRONT TIRE Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
17. REAR TIRE Maxxis Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead
18. CRANKSET Race Face Aeffect ebike, 165mm
19. RINGS Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
20. PEDALS N/A
21. CHAIN Sram GX Eagle, 12s, Powerlock
22. REAR DERAILLEUR Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
23. CASSETTE Sram XG-1275, 10-52T, 12s
24. MOTOR Bosch Performance Line CX Cruise (25Km/h) Smart System
25. BATTERY Bosch Powertube 750Wh
26. DISPLAY Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller
27. DERAILLEUR HANGER Mondraker M068
