01. FRAME Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design
01A. FRAME Flatmount brake compatible, integrated dropout speed sensor.
02. FORK Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork
03. REAR SHOCK N/A
04. HEADSET OnOff gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45şx45ş, bottom 51.9x40x8x45şx45ş
05. GRIPS Barium gravel dark grey
06. HANDLE BAR OnOff Barium gravel 18ş bar flare. Width sizes S/M: 440mm, size L/XL: 460mm
07. STEM OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7ş, length: sizes S/M: 70mm, size L: 80mm, XL: 90mm
08. SEAT POST OnOff Barium gravel microadjust diameter 27.2mm, length 400mm
09. SADDLE FIZIK Terra Argo X7 150mm
10. FRONT BRAKE Sram Rival Etap AXS 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
11. FRONT BRAKE ROTOR Centerline 160mm IS 6 bolts one-piece roto
12. REAR BRAKE Sram Rival Etap AXS, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
13. REAR BRAKE ROTOR Centerline 160mm IS 6 bolts one-piece roto
14. BRAKE LEVERS Sram Rival, contact point adjustment, tooled reach adjust, plastic levers
15. SHIFTER REAR Sram Rival Etap AXS 12s
16. REAR DERAILLEUR Sram Rival XPLR Etap AXS, 12s
17. CASSETTE Sram XG-1251 10-44T, 12s
18. CHAIN Sram Rival, 12s, Powerlock
19. CRANKSET Sram Rival 1 GLS DUB Wide, S: 170mm, M: 172,5mm, L: 172,5mm, XL: 175mm.
20. BOTTOM BRACKET Mahle pressfit, sealed bearings, w/ torque sensor
21. FRONT HUB Mavic, 12x100mm, IS 6 bolts
22. REAR HUB Mahle X20 Drive Unit, XDR freehub
23. SPOKES/NIPPLES Mavic Steel double butted flat spokes
24. RIMS Mavic Allroad Disc, UST, 22mm internal width, hookless, 28 spokes
25. FRONT TIRE Maxxis Rambler 700x40, tubeless ready, dual compound EXO protection, 60 TPI, folding bead, tan wall
26. REAR TIRE Maxxis Rambler 700x40, tubeless ready, dual compound EXO protection, 60 TPI, folding bead, tan wall
27. SEALANT N/A
28. VALVES Mavic
29. RIM TAPE Mavic
30. MOTOR Mahle X20 Drive Unit
31. BATTERY Mahle X20 IX350Wh
32. DISPLAY Pulsar One Wireless
33. FEATURES 4 Optional range extender: Mahle e185 , 172Wh
34. FEATURES 5 Weight 13.1 KG
