Please note - specifications subject to change without prior notice.
01. FRAME New Trail 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry
02. SIZES S: 380mm / M: 420mm / L: 450mm / XL: 500mm
03. REAR SHOCK Fox Float DPS Factory Kashima evol LV, 205x57.5mm. Settings: Compression 3 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
04. SHOCK SETTINGS Light compression, extralight rebound, air volume spacer 0.6
05. FORK Fox 36 29 Float GRIP2 Factory Kashima, 150mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
06. HEADSET Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
07. STEM Onoff Krypton FG 30mm, CNC, 31.8mm barbore
08. HANDLEBAR Onoff Kripton Carbon 1.0, rise: 25mm, width: 800mm, 9 degrees backsweep, 5 degrees upsweep, 31.8mm barbore
09. GRIPS Onoff Diamond, 1lock-on, 135mm
10. SEATPOST Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L/XL size: 475.1x175mm
11. SADDLE Fizik Antares R7
12. FRONT BRAKE Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
13. REAR BRAKE Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
14. BRAKE LEVER Sram G2 RS, SwingLink, tool-free reach adjust
15. RIMS DT Swiss XM1700 Spline 29, 30mm internal width, welded aluminum, tubeless ready, 28 spokes
16. SPOKES DT Competition, straightpull
17. FRONT HUB DT 350, Boost 15x110mm, IS 6 bolts
18. REAR HUB DT 350, Boost 12x148mm, 36T SL Ratchet system, IS 6 bolts, XD freehub
19. FRONT TYRE Maxxis Dissector DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
20. REAR TYRE Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead
21. CRANKSET Sram X1 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
22. CHAINRING 32T, CNC-machined alloy, X-SYNC 2
23. BOTTOM BRACKET Sram DUB BSA, sealed bearings, 73mm
24. PEDALS -
25. CHAIN Sram GX Eagle, 12s, Powerlock
26. FRONT DERAILLEUR -
27. REAR DERAILLEUR Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
28. SHIFT LEVERS Sram Trigger GX Eagle, 12s, X-Actuation 1:1
29. CASSETTE Sram XG-1275, 10-52T, 12s
