01. FRAME Play 24 6061 Alloy Stealth evo, hydroformed tubing, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, QR 9mm rear axle, 1x drivetrain compatible
02. SIZES One size: 320mm
03. REAR SHOCK -
04. SHOCK SETTINGS -
05. FORK RockShox Judy Silver TK 26, 100mm, TurnKey, Solo Air, tapered steerer tube, 9x100mm axle, 30mm steel stanchions, 40mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
06. HEADSET Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreesx45 degrees, bottom 51.9x40x8x45 degreesx45 degrees
07. STEM Onoff Sulfur FG 30mm 0 degrees, 6061 forged alloy, 31.8mm barbore
08. HANDLEBAR MDK XC 1.0, 6061 alloy, rise: 25mm, width: 580mm, 9 degrees backsweep, 5 degrees upsweep, 31.8mm barbore
09. GRIPS Onoff Twin, 1lock-on, 135mm
10. SEATPOST MDK XC 0-R, 6061 T6 Alloy, diameter 31.6mm, length 300mm
11. SADDLE SDG Fly JR
12. FRONT BRAKE Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
13. REAR BRAKE Sram Level, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad
14. BRAKE LEVER Sram Level, tooled reach adjust, lever pivot bushings
15. RIMS MDK-XP1 24 TLR, 23mm internal width, tubeless ready, 32 spokes
16. SPOKES CN round stainless steel
17. FRONT HUB Formula DC20LW, 9x100mm, cup & cone ball bearings, IS 6 bolts
18. REAR HUB Mahle-Ebikemotion X-35
19. FRONT TYRE Kenda Booster 24x2.4 single compound 30TPI, wire bead
20. REAR TYRE Kenda Booster 24x2.4 single compound 30TPI, wire bead
21. CRANKSET Prowheel, Direct mount chain ring, 127mm
22. CHAINRING 28T, steel
23. BOTTOM BRACKET Samox BSA, 73mm
24. PEDALS -
25. CHAIN Sram PC1110 11s, Powerlock
26. FRONT DERAILLEUR -
27. REAR DERAILLEUR Sram NX, 11s, long cage, X-actuation 1:1
28. SHIFT LEVERS Sram trigger NX 11s, X-actuation 1:1
29. CASSETTE Sram PG 1030 11-42T, 11s
30. MOTOR Mahle-Ebikemotion X-35
31. BATTERY Mahle-Ebikemotion Internal 250Wh
32. DISPLAY Mahle-Ebikemotion
33. HANGER M073
