01. FRAME Foxy 29 Stealth Air full Carbon, Zero Suspension System
02. SIZES S: 380mm / M: 420mm / L: 450mm / XL: 500mm
03. REAR SHOCK Fox Float-X LV EVOL Performance, 205x65mm. Settings: compression 3 positions lever, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings
04. SHOCK SETTINGS Light compression, extralight rebound, air volume spacer 0.6
05. FORK Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload
06. HEADSET Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
07. STEM Onoff Sulfur FG 30mm 0 degrees, 6061 forged alloy, 31.8mm barbore
08. HANDLEBAR Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degrees backsweep, 5 degrees upsweep, 31.8mm barbore
09. GRIPS Onoff Diamond, 1lock-on, 135mm
10. SEATPOST Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L size: 425x150mm, XL size: 465x170mm
11. SADDLE SDG BEL-AIR 3.0, LPU foam, steel rails
12. FRONT BRAKE Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
13. REAR BRAKE Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads
14. BRAKE LEVER Sram G2 R, tool-free reach adjust
15. RIMS DT Swiss E1900 Spline 29, 30mm internal width, sleeved aluminum, tubeless ready, 28 spokes
16. SPOKES DT Champion, straightpull
17. FRONT HUB DT 370, Boost 15x110mm, IS 6 bolts
18. REAR HUB DT 370, Boost 12x148mm, 18T Ratched LN system, IS 6 bolts
19. FRONT TYRE Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
20. REAR TYRE Maxxis Minion DHR II 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead
21. CRANKSET Truvativ Descendant 6K Eagle, Boost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm
22. CHAINRING 32T, steel, X-Sync 2
23. BOTTOM BRACKET Sram DUB BSA, sealed bearings, 73mm
24. PEDALS -
25. CHAIN Sram NX Eagle, 12s, Powerlock
26. FRONT DERAILLEUR -
27. REAR DERAILLEUR Sram Trigger NX Eagle, 12s, X-Actuation 1:1
28. SHIFT LEVERS Sram Trigger NX Eagle, 12s, X-Actuation 1:1
29. CASSETTE Sram XG-1230, 11-50T, 12s
