Please note - specifications subject to change without prior notice.
01. FRAME Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery with integrated alloy cover, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link
02. SIZES S: 380mm / M: 420mm / L: 450mm / XL: 490mm
03. REAR SHOCK Fox Float-X LV Factory Kashima, 205x65mm. Settings: compression 3 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
04. SHOCK SETTINGS CEC001 compression, Medium rebound, 0.2 volume spacer
05. FORK Fox 38 29 Float GRIP2 Factory Kashima, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
06. HEADSET Onoff Saturn tapered for 1-1/8" to 1-1/2" head tube, ACB sealed bearings, top 41x30.2x7x45 degreesx45 degrees, bottom 51.9x40x8x45 degreesx45 degrees
07. STEM Onoff Sulfur FG 30mm 0 degrees, 6061 forged alloy, 31.8mm barbore
08. HANDLEBAR Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degrees backsweep, 5 degrees upsweep, 31.8mm barbore
09. GRIPS Onoff Diamond, 1lock-on, 135mm
10. SEATPOST Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M/L size: 418.3x150mm, XL size: 475.1x175mm
11. SADDLE Fizik Terra Aidon X5 145mm
12. FRONT BRAKE SRAM G2 RS, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
13. REAR BRAKE SRAM G2 RS, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
14. BRAKE LEVER SRAM G2 RS, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
15. RIMS Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
16. SPOKES Mavic J-bend duble butted, contactless lacing
17. FRONT HUB Mavic, Boost 15x110mm, IS 6 bolts
18. REAR HUB Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
19. FRONT TYRE Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
20. REAR TYRE Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
21. CRANKSET Race Face Aeffect ebike, 165mm
22. BOTTOM BRACKET -
23. CHAINRING Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
24. PEDALS -
25. CHAIN Sram NX Eagle, 12s, Powerlock
26. FRONT DERAILLEUR -
27. REAR DERAILLEUR Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
28. SHIFT LEVERS Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click
29. CASSETTE Sram XG-1230, 11-50T, 12s
30. MOTOR Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3
31. BATTERY Bosch Powertube 750Wh
32. DISPLAY Bosch Kiox 300
33. HANGER M068
