Please note - specifications subject to change without prior notice.
01. FRAME Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing
02. SIZES S: 380mm / M: 420mm / L: 450mm / XL: 490mm
03. REAR SHOCK Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
04. SHOCK SETTINGS Medium compression, Medium rebound, 0.4 volume spacer
05. FORK Fox 38 29 Float GRIP Performance, 160mm, e-bike optimized, tapered steerer tube, Boost 15x110mm axle, 44mm offset, 68mm OD crown. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload
06. HEADSET Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
07. STEM Onoff Krypton FG 30mm, CNC, 31.8mm barbore
08. HANDLEBAR Onoff Krypton 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 degrees backsweep, 5 degrees upsweep, 31.8mm barbore
09. GRIPS Onoff Diamond, 1lock-on, 135mm
10. SEATPOST Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm
11. SADDLE Fizik Terra Aidon X5 145mm
12. FRONT BRAKE Sram G2 RS, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
13. REAR BRAKE Sram G2 RS, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
14. BRAKE LEVER Sram G2 RS, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
15. RIMS Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
16. SPOKES Mavic J-bend duble butted, contactless lacing
17. FRONT HUB Mavic, Boost 15x110mm, IS 6 bolts
18. REAR HUB Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts
19. FRONT TYRE Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
20. REAR TYRE Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead
21. CRANKSET Race Face Aeffect ebike, 165mm
22. BOTTOM BRACKET -
23. CHAINRING Sram X-Sync 2 Eagle 34T, alloy, narrow-wide, 104 BCD
24. PEDALS -
25. CHAIN Sram NX Eagle, 12s, Powerlock
26. FRONT DERAILLEUR -
27. REAR DERAILLEUR Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1
28. SHIFT LEVERS Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click
29. CASSETTE Sram XG-1230, 11-50T, 12s
30. MOTOR Bosch Performance Line CX Cruise (25Km/h) GEN4 BS3
31. BATTERY Bosch Powertube 750Wh
32. DISPLAY Bosch Kiox 300
33. HANGER M068
